Quick Details

  • Type: Wrapping Machine, Wrapping Machine
  • Condition: New, New
  • Application: Beverage, Commodity, Machinery & Hardware, Medical, Machinery & Hardware
  • Packaging Type: Belt, Capsule, Cartons, Case, Cartons
  • Packaging Material: Paper, Plastic, Metal & Wooden
  • Automatic Grade: Semi & Fully Automatic, Semi & Fully Automatic
  • Driven Type: Electric, Electric
  • Voltage: 1.2kw
  • Power: 220V
  • Place of Origin: Guangdong, China (Mainland), Guangdong China (Mainland)
  • Brand Name: JoyPack, JoyPack
  • Model Number: stretch_wrapping_machine 1
  • Dimension(L*W*H): L1400mm W1400mm H2100mm
  • Weight: 2000kg
  • Certification: CE SGS UKAS
  • Color: Blue & Yellow

Packaging & Delivery

Packaging Details Standard Export strong wooden case (Wooden case, Packing size: L 2.65 X W 165 XH 0.75m Transportation: 20 feet container: 6 PCs)
Delivery Time Within 6-15 days after getting the formal order and payment

Stretch wrapping machine









Simple Pallet Wrap machine





This wrapping machine use LLDPE stretch film as the main packing material to wrap the bulk cargos stacked on the pallet, Which make goods more stable, beautiful, neat, and effect with waterproof, dustproof, prevent scattering, theft proof, convenient into and out.







Basic characteristics:



1. Adopt PLC programmable controller control. Can set wrapping circle number, can choose local strengthening, automatic reset, etc.



2. Equipped with human-machine interface, parameters setting simply and conveniently.



3. Designed concisely and maintain conveniently



4. Closed structure, strong and durable.













Specification:


Simple Pallet Wrap machine as the most simple wrap machine in pallet series has a friendly operate panel

and competitive price.
Top plate is optional and specially designed for holding an unstable product.
Ramp is optional and specially designed for easy loading a pallet on the turntable.



Ø Technology data:

Model

GM-1650E

Wrap size(L×W

(500-1200)mm×(500-1200)mm

Wrap height(max)

L type:1800mm  H type:2400mm   Y type:2800mm

Wrap efficiency

20-40 Pallets/Hour

Turntable speed

0-12rpm Adjustable turntable speed

Turntable diameter

1650mm

Turntable height

78mm

Turntable weight capacity (max)

2000kg

Film carriage

Film carriage with Mechanical brake (variable film tension control)

Lift system

Double chain structure,lift speed adjustable

Control system

PLC control,wrap layers adjustable,Turntable automatic reset,photo-eyes auto-height sensing

Total weight(max)

700kg

Machine size

2745mm×1650mm×(2270-2870)mm

Power/voltage

Turntable:0.75kw  Film carriage:0.35kw  Lift system: 0.37kw`/AC220V

Top plate(optional)

Motor-Driven

Ramp(optional)

Custom made











Pls Contact  --- Tony

Mobile:0086 137 1282 7205

E-mail: joypack#joypack.cn (# to @)

Website: http://www.dgdbd.com   http://www.joypack1688.cn       http://www.joypack.cn



Dongguan JoyPack Packing Materials & Machine Co.,Ltd (China)

Official Unified Hotline : 4008-010-260
Tel: 86-0769-85473185   87380864
Fax: 86-0769-85473272
Add: Sha`Hu`Kou Area,Chang'ping Town, Dongguan City ,Guangdong Province ,China  (523557)
